Liquid Filling Machine Technical Specifications
Professional liquid filling machine with production speed up to 6-25 pcs/m (varies by model), machine dimensions: KY-BG100: 980×550×1450mm, KY-BG250: 1000×550×1550mm, KY-BG500: 1100×550×1600mm, KY-BG1000: 1300×670×1650mm, KY-BG2000: 1650×700×1700mm, weight: 35kg (KY-BG100, KY-BG250), 45kg (KY-BG500, KY-BG1000), 75kg (KY-BG2000.Ideal for Automatic filling machine, Beverage filling, Bottling equipment, Liquid filling, Multi-container filling, Oil filling machine, Packaging automation, Pharmaceutical filling, Plc control system, Stainless steel filling packaging applications.Supports N/A bag types.
Core Technical Specifications
- Production Speed: 6-25 pcs/m (varies by model)
- Applicable Products: Vegetable oil, detergents, beverages, pharmaceuticals, and other liquid products
- Machine Dimensions: KY-BG100: 980×550×1450mm, KY-BG250: 1000×550×1550mm, KY-BG500: 1100×550×1600mm, KY-BG1000: 1300×670×1650mm, KY-BG2000: 1650×700×1700mm
- Machine Weight: 35kg (KY-BG100, KY-BG250), 45kg (KY-BG500, KY-BG1000), 75kg (KY-BG2000
- Power Supply & Power: Single-phase 220V 50Hz
Packaging Types & Formats
- Bag Type: N/A
B2B Terms & Conditions
- Customizable Modules: Bottle unscrambling, automatic filling, automatic capping, automatic cap pressing and screwing, automatic weight detection, automatic magnetic induction sealing, automatic labeling, automatic coding, collection platform
- Lead Time:15-30 days (typical)
- Samples: Available upon request
- OEM/ODM: Custom development available
Applications
- Automatic filling machine
- Beverage filling
- Bottling equipment
- Liquid filling
- Multi-container filling
- Oil filling machine
- Packaging automation
- Pharmaceutical filling
- Plc control system
- Stainless steel filling
| Specification | KY-BG100 | KY-BG250 | KY-BG500 | KY-BG1000 | KY-BG2000 |
|---|---|---|---|---|---|
| Filling Range | 10-100ml | 30-250ml | 100-500ml | 200-1000ml | 500-2000ml |
| Production Speed | 20-25 pcs/m | 20-25 pcs/m | 12-18 pcs/m | 8-14 pcs/m | 6-10 pcs/m |
| Air Compressor Displacement | 5.7 ft3/min | 5.7 ft3/min | 5.7 ft3/min | 5.7 ft3/min | 8.8 ft3/min |
| Power Supply | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz |
| Dimensions | 980×550×1450mm | 1000×550×1550mm | 1100×550×1600mm | 1300×670×1650mm | 1650×700×1700mm |
| Weight | 35kg | 35kg | 45kg | 45kg | 75kg |
